Basin and toilet options

The Vienna bathroom range includes basin and toilet suite options with a consistent design style.

Installation

Vienna basins options are either counter top or wall hung. Each toilet suite is for back to wall installation.

Comfort height, short projection toilets

Vienna includes suites with higher than usual seat height (460 mm) for easier access and greater comfort. A short projection suite (595 mm) is also available and is ideal for bathrooms with limited space.

Built to last

Premium glazed basin and toilet finishes are subjected to 200 hours of corrosion testing to ensure durability.

Curved Design

An elegant, beautifully rounded design in a bright white finish.

Wels rating

4 Stars, 3.5 L average flush

Type

Wall faced, accessible.

Installation

AS1428 Compliance: Refer to the latest standard to ensure installation meets the requirements. The installation of the toilet suite shall be in accordance with the normal minimum drain line grade requirements in AS/NZS 3500.2.

Pan

Rimless

Cistern

R&T dual flush concealed cistern (4.5 L / 3 L, 3.5 L avg flush volume)

Trap(s)

Universal (S or P Trap)

Set outs

S-trap set out 140 mm - 250 mm as standard. P-trap set out 180 mm floor to centre of outlet.

Seat

Lock-in single flap blue toilet seat is provided as standard. UF compression moulded toilet seat, fitted with buffers and metal hinges.

Materials

Vitreous china pan and cistern, compression moulded polymer seat

Weight

Pan 44.1 kg, cistern 7.0 kg

Colours

White

Parts list

Pan, seat, hinges, concealed cistern, push plate, S-trap connector, seal ring, fixing plate, fixing screw, floor fixing screw.

Warranty

Commercial warranty: 10 years vitreous china cistern and pan replacement of product; 5 years replacement seat; 2 years valves and fittings; 1 year seals, buttons and labour (refer to Service & Warranty page for details).

Maintenance and care instructions

Clean with a soft cloth and warm soapy water as necessary - rinse and dry after cleaning. Avoid using abrasive or acid-based cleaning products.
